-32-
3). You now hear the sound from the
external device played back through
the loudspeakers .
4). Touch the volume+/- sections on
touch screen or use the VOL+/- on
the panel to adjust the volume level.
Touch Screen Operation
2). In main menu, touch “ AUX ”
ICON or press “MOD” button on
control panel to enter AUX IN mode .
AUX Operation
On the front panel of this unit, there is an
AUX IN jack, follow the diagram below to
connect analogue replay devices(only
for the Audio connect, if you want to
connect the Video, please plug the RCA
on the back of the unit .) .
Use this jack to replay sound of other
replay equipment such as Digital Video
players, computers, etc. Via the loud-
speakers.
1). Please connect the external device
with stereo jack (3.5mm)plug the Aux in
socket .
AUX IN JACK FRONT PANEL
AUX IN
Ground
Right
Left
AUX IN
AUX IN
