Mc-1500lc-mm & sm gigabit triple-speed converter

MC-1500LC-MM & SM
Gigabit Triple-Speed Converter
10/100/1000 to 1000SX / LX (SFP) Converter Series
- 1 -
www.lynnelec.com
Introduction:
The MC-1500 media converter is specifically designed
to offer fiber advantages for mission-critical networks
like Telco/ISP backbones, cable operators, banking
and enterprise networks. The MC-1500 can reduce
network downtime and increase Quality of Service
levels. The converters are completely transparent
when installed, so the network performs exactly the
way it would do normally – only now, it can incorporate
both copper and fiber mediums.
This flexibility in cabling allows network managers to
put fiber cables anywhere within a network without
changing the arrangement of the copper-based Gigabit
segments. Their compact size allows the converters to
be wall-mounted to save space. Several converters can be simultaneously installed by using the MC-1600-4 4-slot and
MC-1600-12, 19" rack-mountable chassis.
The MC-1500 takes advantage of intelligent connection technology to support Auto-negotiation, thereby eliminating the
hassle of manually configuring or monitoring settings. This ensures plug-n-play operability.
Main Features:
Standards:
Complies with IEEE 10/100Base-TX, IEEE 802.3ab 1000Base-T and IEEE 802.3z 1000Base-LX standards
Interface:
One 10/100/1000 Mbps Ethernet port
Auto MDI/MDI-X support on RJ-45 port
One SFP slot for Gigabit links
Extends distances up to 110Km (Single Mode)
Management:
Alarm LED illuminates to indicate link failure
Status LEDs for easy monitoring of device’s status
Mechanical & Environmental:
External power supply
Chassis-compliant (internal power supply)
FCC Class A & CE approved
RoHS compliant
