Thank you for purchasing Cerwin-Ve g a
P rofessional SDS-525T two-way, bass-re f l e x
system. This speaker system is specifically
designed for professional applications includ-
ing fore g round and background music play-
back. Available in black or white, the SDS-
525T includes a pro p r i e t a r y, adjustable-
mounting bracket.
The SDS-525T has a built-in transformer for
c o m m e rcial and residential distributed sys-
tem applications. The combination 4-Ohm
selector switch and adjutable transformer set-
tings gives it maximum flexibility for use in
100 volt/70.7 volt systems or traditional
loudspeaker applications.
Other features include:
• Voice-matched, full-range re s p o n s e
• Versatile mounting brackets for a variety of
placement options
• Small, high-impact, polyresin cabinets with
sleek contours and durable metal grills
• Barrier strip type speaker connections
• Weather re s i s t a n t
For proper surround sound setup, please re f e r
to the owner’s manuals that came with your
components for instructions and cautions.
N O T E : Continuous, excessive exposure to sound
p re s s u re levels in excess of 85 dB may cause hear -
ing loss. Cerwin-Vega audio/video speaker syste m s
a re capable of producing sound pre s s u re levels
g reater than 85 d B .
I
N T R O D U C T I O N
• Make sure all audio equipment is off before
making connections.
• The speaker connections are barrier
t e r m i n a l s, denoted as red for (+) and
black for (–).
• Separate wires and attach them to
terminals, as shown on the left.
NOTE: You may have to temporarily re m o v e
the tilt bracket to access the barrier terminals.
WARNING: Do not turn selector switch to 4
ohms while connected to a 100 volt or 70.7
volt constant voltage amplifier.
C
O N N E C T I N G
T
H E
S
P E A K E R S
P
O W E R
S
E L E C T I O N S
100 Vo l t 4 2 W 2 6 W 1 6 W 8 W
70.7 Vo l t 2 2 W 1 3 W 8 W 4 W
