1. Speaker Connection
2. Battery +12V Input 3. Remote Turn-on Input
4. Ground
1. Remote Bass Level Control
2. RCA Input Jacks
3. Bridge in
2 1 5 6
2 1 3 4
APSM-1300
4. Bridge out
5. Power Indicator LED
6. Protection Circuit Indicator LED
3 4
