16 | English
1 619 P09 555 | (20.7.11) Bosch Power Tools
Intended Use
The machine is intended for lengthways and crossways cut-
ting of wood with straight cutting lines as well as mitre cuts in
wood while resting firmly on the workpiece. With suitable saw
blades, thin-walled non-ferrous metals, e. g., profiles, can al-
so be sawed.
Working ferrous metals is not permitted.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Blade guard
2 Lock-off button for On/Off switch
3 On/Off switch
4 Auxiliary handle (insulated gripping surface)
5 Spindle lock button
6 Scale for mitre angle
7 Wing bolt for parallel guide
8 Wing bolt for bevel-angle preselection
9 Cutting mark, 0°
10 Cutting mark, 45°
11 Parallel guide*
12 Retracting blade guard
13 Riving knife (GKS 85 G)
14 Base plate
15 Lever for retracting blade guard
16 Wing bolt for bevel-angle preselection
17 Sawdust ejector
18 Handle (insulated gripping surface)
19 Allen key
20 Clamping bolt with washer
21 Clamping flange
22 Saw blade*
23 Mounting flange
24 Saw spindle
25 Screw for attachment of riving knife (GKS 85 G)
26 Extraction adapter*
27 Fastening screw for extraction adapter (GKS 85)*
28 Clamping lever for cutting-depth preselection
29 Cutting-depth scale
30 Set of screw clamps*
31 Guide rail*
32 Connection piece*
33 Vacuum hose*
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Circular Saw GKS 85
Professional
GKS 85 G
Professional
Article number 3 601 E7A 0.. 3 601 E7A 9..
Rated power input W 2200 2200
No-load speed min -1 5000 5000
Rotational speed under load, max. min -1 3500 3500
Cutting depth, max.
– for 0° bevel angle
– for 45° bevel angle
mm
mm
85
65
85
65
Spindle lock z z
Constant electronic control – z
Reduced starting current z z
Base plate dimensions mm 383 x 170 406 x 208
Saw blade diameter, max. mm 235 235
Saw blade diameter, min. mm 230 230
Blade thickness, max. mm 2.2 2.2
Tooth thickness/setting, max. mm 3.2 3.2
Tooth thickness/setting, min. mm 2.0 2.0
Mounting bore mm 30 30
Weight according to EPTA-Procedure 01/2003 kg 7.5 7.8
Protection class / II / II
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
