English | 19
Bosch Power Tools 1 609 929 U17 | (4/8/10)
Assembly
Delivery Scope
Please also observe the represen-
tation of the delivery scope at the
beginning of the operating instruc-
tions.
Before assembling the saw stand, check if all
parts listed below are provided:
Additionally required tools (not in delivery
scope):
– Open-end spanner (10 mm)
Assembling the Saw Stand
– Carefully remove all parts included in the de-
livery from their packaging.
– Remove all packaging material.
Setting Up the Saw Stand (see figures A1 – A2)
– Lay the saw stand upside down on the floor
(legs facing upward).
– Push the locking pin 15 in and tilt the leg up-
ward until the locking pin can be heard to en-
gage.
– Repeat this workstep with the other three
legs.
– Turn around the saw stand to the working
position.
– Ensure that the saw stand is stable and that
all locking pins have engaged.
The saw stand is easily aligned with the height-
adjustable leg 9.
– Screw the leg in or out until the saw stand is
aligned level and all four legs face against the
floor.
Mounting the Roller Stand (see figure B1)
– Unscrew the Phillips screw of the roller
stand 7 with the Phillips screwdriver 14 pro-
vided.
If required, counter-hold the lock nut on the
other side of the roller stand using a spanner
(size 10 mm).
– Disassemble the roller stand 7.
There are different possibilities to arrange the
individual rollers to the workpiece support with
the internally-threaded rod (see figure).
– Arrange the individual parts as required and
slide the internally-threaded rod through the
rollers and the workpiece support 1.
– Screw all parts together again.
Mounting the Workpiece Support
(see figure B2)
– Loosen the locking knobs 3 and pull the table
extensions 2 via both sides of the saw stand
lightly outward.
– Slide the workpiece supports 1 from the left
and right each into the upper groove of the
saw stand or the table extension.
The length stops 8 must face outward.
– Tighten the locking knob 6 to lock the work-
piece support.
Preparing the Saw Stand
Preparing the Attachment Sets
(see figures C1 – C4)
– To release the attachment sets 4, press but-
tons 16 each and open the levers 17.
– Measure the distance x between the mount-
ing holes and your power tool.
– Position the attachment sets 4 centred on
the saw stand and at the matching clearance
x to each other.
– Lock the levers 17 again. The attachment
sets are now firmly positioned on the saw
stand.
No. Designation Quantity
Saw stand GTA 3800 1
4 Attachment set 2
1 Workpiece support 2
7 Roller stand 2
14 Socket spanner/Allen key/
Phillips screwdriver
1
19 Power tool fastening kit
consisting of:
– Hexagon bolt
(M8 x 45)
– Washer
4
4
