ﻲﺑﺮﻋ
| 123
Bosch Power Tools 2 609 140 654 | (20.7.11)
ﺕﺍﺯﺍﺰﺘﻫﻻﺍﻭ ﺞﻴﺠﻀﻟﺍ ﻦﻋ ﺕﺎﻣﻮﻠﻌﻣ
. EN 60745 ﺐﺴﺣ ﺕﻮﺼﻟﺍ ﺕﺎﺳﺎﻴﻗ ﻢﻴﻗ ﺪﻳﺪﲢ ﻢﺗ
ﺕﻮﺼﻟﺍ ﻂﻐﺿ یﻮﺘﺴﻣ :ﺓﺩﺎﻋ ( A ﻉﻮﻧ) ﺯﺎﻬﳉﺍ ﺞﻴﺠﺿ یﻮﺘﺴﻣ ﺔﻤﻴﻗ ﻎﻠﺒﺗ
ﺏﺍﺮﻄﺿﺍ .( A ﻉﻮﻧ) ﻞﺒﻴﺴﻳﺩ 93 ﺕﻮﺼﻟﺍ ﺓﺭﺪﻗ یﻮﺘﺴﻣ .( A ﻉﻮﻧ) ﻞﺒﻴﺴﻳﺩ 82
.ﻞﺒﻴﺴﻳﺩ 3 = K ﺱﺎﻴﻘﻟﺍ
!ﻊﻤﺳ ﺔﻴﻗﺍﻭ ﺪﺗﺭﺍ
K ﺕﻭﺎﻔﺘﻟﺍﻭ (ﺕﺎﻫﺎﲡﺍ ﺔﺛﻼﺜﺑ ﺕﺎﻬﺠﺘﳌﺍ ﻉﻮﻤﳎ) a
h
ﺕﺍﺯﺍﺰﺘﻫﻻﺍ ﺙﺎﻌﺘﺑﺍ ﺔﻤﻴﻗ
: EN 60745 ﺐﺴﺣ ﺖﺒﺴ ﹸﺣ
، ٢ ﺎﺛ/ﻡ 1,5 = K ، ٢ ﺎﺛ/ﻡ 7,0 = a
h
:ﻥﺩﺎﻌﳌﺍ ﺐﻘﺛ
. ٢ ﺎﺛ/ﻡ 1,5 = K ، ٢ ﺎﺛ/ﻡ 4,0 = a
h
:ﺐﻟﺍﻮﻠﻟﺍ ﻂﺑﺭ
ﺏﻮﻠﺳﺍ ﺐﺴﺣ ﻩﺬﻫ ﺕﲈﻴﻠﻌﺘﻟﺍ ﰲ ﺭﻮﻛﺬﳌﺍ ﺕﺍﺯﺍﺰﺘﻫﻻﺍ یﻮﺘﺴﻣ ﺱﺎﻴﻗ ﻢﺗ ﺪﻘﻟ
ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ ﺔﻧﺭﺎﻘﳌ ﻪﻣﺍﺪﺨﺘﺳﺍ ﻦﻜﻤﻳﻭ EN 60745 ﻦﻤﺿ ﲑﻌﻣ ﺱﺎﻴﻗ
.ﻲﺋﺪﺒﻣ ﻞﻜﺸﺑ ﺕﺍﺯﺍﺰﺘﻫﻼﻟ ﺽﺮﻌﺘﻟﺍ ﺮﻳﺪﻘﺘﻟ ﻢﺋﻼﻣ ﻪﻧﺃ ﲈﻛ .ﺾﻌﺒﻟﺍ ﺎﻬﻀﻌﺒﺑ
.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻠﻟ ﺔﻴﺳﺎﺳﻻﺍ ﺕﺎﻣﺍﺪﺨﺘﺳﻻﺍ ﺭﻮﻛﺬﳌﺍ ﺕﺍﺯﺍﺰﺘﻫﻻﺍ یﻮﺘﺴﻣ ﻞﺜﻤﻳ
ﻭﺃ ﺔﻔﻟﺎﳐ ﻞﻐﺷ ﺩﺪﻌﺑ یﺮﺧﺃ ﺕﺎﻣﺍﺪﺨﺘﺳﻻ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻝﲈﻌﺘﺳﺍ ﻢﺗ ﻥﺇ ﲈﻨﻴﺑ
ﺽﺮﻌﺘﻟﺍ ﻚﻟﺫ ﺪﻳﺰﻳ ﺪﻗﻭ .ﺕﺍﺯﺍﺰﺘﻫﻻﺍ یﻮﺘﺴﻣ ﻒﻠﺘﳜ ﺪﻘﻓ ،ﺔﻴﻓﺎﻛ ﲑﻏ ﺔﻧﺎﻴﺼﺑ
.ﺢﺿﺍﻭ ﻞﻜﺸﺑ ﻞﻐﺸﻟﺍ ﺓﱰﻓ ﻝﺍﻮﻃ ﺕﺍﺯﺍﺰﺘﻫﻼﻟ
ﺓﺎﻋﺍﺮﻣ ﻢﺘﻳ ﻥﺃ ،ﻖﻴﻗﺩ ﻞﻜﺸﺑ ﺕﺍﺯﺍﺰﺘﻫﻼﻟ ﺽﺮﻌﺘﻟﺍ ﺮﻳﺪﻘﺗ ﻞﺟﺃ ﻦﻣ ﻲﻐﺒﻨﻳ ﲈﻛ
ﻞﻤﺤﺑ ﻪﻠﻴﻐﺸﺗ ﻥﻭﺩ ﻦﻜﻟﻭ ﺎﲠ ﻞﻤﻌﻳ ﻲﺘﻟﺍ ﻭﺃ ﺯﺎﻬﳉﺍ ﺎﳍﻼﺧ ﺄﻔﻄﻳ ﻲﺘﻟﺍ ﺕﺎﻗﻭﻷﺍ
ﺓﺪﻣ ﻞﻣﺎﻛ ﱪﻋ ﺢﺿﺍﻭ ﻞﻜﺸﺑ ﺕﺍﺯﺍﺰﺘﻫﻼﻟ ﺽﺮﻌﺘﻟﺍ ﻚﻟﺫ ﺾﻔﳜ ﺪﻗﻭ .ﻼﻌﻓ
.ﻞﻤﻌﻟﺍ
:ﻼﺜﻣ ،ﺕﺍﺯﺍﺰﺘﻫﻻﺍ ﲑﺛﺄﺗ ﻦﻣ ﻡﺪﺨﺘﺴﳌﺍ ﺔﻳﺎﻗﻮﻟ ﺔﻴﻓﺎﺿﺇ ﻥﺎﻣﺃ ﺕﺍﺀﺍﺮﺟﺇ ﺩﺪﺣ
.ﻞﻤﻌﻟﺍ ﺕﺎﻳﺮﳎ ﻢﻴﻈﻨﺗﻭ ﻦﻳﺪﻴﻟﺍ ﺔﺌﻓﺪﺗ ،ﻞﻐﺸﻟﺍ ﺩﺪﻋﻭ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺔﻧﺎﻴﺻ
ﻖﻓﺍﻮﺘﻟﺍ ﺢﻳﴫﺗ
ﻖﻓﺍﻮﺘﻳ “ﺔﻴﻨﻔﻟﺍ ﺕﺎﻧﺎﻴﺒﻟﺍ” ﰲ ﻑﻮﺻﻮﳌﺍ ﺞﺘﻨﳌﺍ ﻥﺄﺑ ،ﺎﻨﺘﻴﻟﻭﺆﺴﻣ ﯽﻠﻋ ﺡﴫﻧ ﺎﻨﻧﺇ
ﺕﺍﺩﺎﺷﺭﺇ ﻡﺎﻜﺣﺃ ﺐﺴﺣ EN 60745 :ﺔﻴﻟﺎﺘﻟﺍ ﺔﻳﺭﺎﻴﻌﳌﺍ ﻖﺋﺎﺛﻮﻟﺍ ﻭﺃ ﲑﻳﺎﻌﳌﺍ ﻊﻣ
. 2006/42/EG ، 2004/108/EG
: (2006/42/EG) یﺪﻟ ﺔﻴﻨﻔﻟﺍ ﻕﺍﺭﻭﻷﺍ
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Dr. Eckerhard Strötgen
Head of Product
Certification
Dr. Egbert Schneider
Senior Vice President
Engineering
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
08.07.2011
ﺐﻴﻛﱰﻟﺍ
ﯽﻠﻋ ﻞﻤﻋ ﻱﺃ ﺀﺍﺮﺟﺇ ﻞﺒﻗ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺔﻜﺒﺸﻟﺍ ﺲﺒﻘﻣ ﻦﻣ ﺲﺑﺎﻘﻟﺍ ﺐﺤﺳﺍ ◀
.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ
ﺩﺪﻌﻟﺍ ﻝﺍﺪﺒﺘﺳﺍ
ﺪﻨﻋ ﺓﺪﺸﺑ ﺏﺎﻘﺜﳌﺍ ﻑﺮﻇ ﯽﻤﳛ ﺪﻗ .ﺓﺪﻌﻟﺍ ﻝﺍﺪﺒﺘﺳﺍ ﺪﻨﻋ ﺔﻴﻗﺍﻭ ﺕﺍﺯﺎﻔﻗ ﺪﺗﺭﺍ
◀
.ﺔﻠﻳﻮﻃ ﺓﱰﻔﻟ ﻞﻤﻌﻟﺍ ﺕﺍﺀﺍﺮﺟﺇ ﺬﻴﻔﻨﺗ
( A ﺓﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ) ﺪﺸﻟﺍ ﻊﻳﴪﻟﺍ ﺏﺎﻘﺜﳌﺍ ﻑﺮﻇ
ﺔﺴﻴﺒﻠﻟﺍ ﻞﺘﻓﺍﻭ ﻡﺎﻜﺣﺈﺑ 1 ﺪﺸﻟﺍ ﻊﻳﴪﻟﺍ ﺏﺎﻘﺜﳌﺍ ﻑﺮﻈﺑ 3 ﺔﻴﻔﻠﳋﺍ ﺔﺴﻴﺒﻠﻟﺍ ﻚﺴﻣﺍ
ﺐﻛﺭ .ﺓﺪﻌﻟﺍ ﺐﻴﻛﱰﺑ ﺢﻤﺴﻳ ﻱﺬﻟﺍ ﺪﳊﺍ ﯽﻟﺇ ➊ ﻥﺍﺭﻭﺪﻟﺍ ﻩﺎﲡﺍ ﻮﺤﻧ 2 ﺔﻴﻣﺎﻣﻷﺍ
.ﺓﺪﻌﻟﺍ
ﻖﻠﻏﺍﻭ ﻡﺎﻜﺣﺈﺑ 1 ﺪﺸﻟﺍ ﻊﻳﴪﻟﺍ ﺏﺎﻘﺜﳌﺍ ﻑﺮﻈﺑ 3 ﺔﻴﻔﻠﳋﺍ ﺔﺴﻴﺒﻠﻟﺍ ﻚﺴﻣﺍ
ﺪﺣ ﯽﻟﺇ ﺓﻮﻘﺑ ﺪﻴﻟﺍ ﺔﻄﺳﺍﻮﺑ ➋ ﻥﺍﺭﻭﺪﻟﺍ ﻩﺎﲡﺍ ﻮﺤﻧ ﺎﻬﻠﺘﻔﺑ 2 ﺔﻴﻣﺎﻣﻷﺍ ﺔﺴﻴﺒﻠﻟﺍ
.ﱄﺁ ﻞﻜﺸﺑ ﻚﻟﺬﺑ ﺏﺎﻘﺜﳌﺍ ﻑﺮﻇ ﻝﺎﻔﻗﺇ ﻢﺘﻳ .ﺡﻮﺿﻮﺑ ﻖﺷﺎﻌﺘﻟﺍ ﺕﻮﺻ ﻉﲈﺳ
ﻉﺰﻧ ﻞﺟﺃ ﻦﻣ ﺲﻛﺎﻌﳌﺍ ﻩﺎﲡﻻﺎﺑ 2 ﺔﻴﻣﺎﻣﻷﺍ ﺔﺴﻴﺒﻠﻟﺍ ﻞﺘﻓ ﺪﻨﻋ ﻝﺎﻔﻗﻹﺍ ﻚﻓ ﻢﺘﻳ
.ﺓﺪﻌﻟﺍ
( B ﺓﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ) ﺐﻟﺍﻮﻠﻟﺍ ﻂﺑﺭ ﺩﺪﻋ
ﻡﺎﻋ ﻢﻘﻟ ﻞﻣﺎﺣ ﹰﲈﺋﺍﺩ ﻞﻤﻌﺘﺴﺗ ﻥﺃ ﻲﻐﺒﻨﻳ 9 ﺐﻟﺍﻮﻠﻟﺍ ﻂﺑﺭ ﻢﻘﻟ ﻡﺪﺨﺘﺴﺗ ﺎﻣﺪﻨﻋ
.ﺐﻟﻮﻠﻟﺍ ﺱﺃﺭ ﻢﺋﻼﺗ ﻲﺘﻟﺍ ﺐﻟﺍﻮﻠﻟﺍ ﻂﺑﺭ ﻢﻘﻟ ﻂﻘﻓ ﻡﺪﺨﺘﺳﺍ . 10
ﺏﺎﻘﺜﳌﺍ ﻑﺮﻇ ﻝﺍﺪﺒﺘﺳﺍ
ﺔﻛﴍ ﻦﺋﺎﺑﺯ ﺔﻣﺪﺧ ﺔﻟﺎﻛﻭ ﺰﻛﺮﻣ ﻞﺒﻗ ﻦﻣ ﺏﺎﻘﺜﳌﺍ ﻑﺮﻇ ﻝﺍﺪﺒﺘﺳﺍ ﻢﺘﻳ ﻥﺃ ﺐﳚ
ﺭﻮﳏ ﺖﻴﺒﺜﺗ ﺔﻴﻧﺎﻜﻣﺇ ﻥﻭﺩ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻠﻟ ﺔﺒﺴﻨﻟﺎﺑ ،ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻠﻟ ﺵﻮﺑ
.ﺏﺎﻘﺜﳌﺍ ﻥﺍﺭﻭﺩ
35–31 ﻦﻣ ﺡﻭﺍﱰﻳ ﹼﺪﺷ ﻥﺍﺭﻭﺩ ﻡﺰﻌﺑ ﺏﺎﻘﺜﳌﺍ ﻑﺮﻇ ﹼﺪﺷ ﹼﻢﺘﻳ ﻥﺃ ﺐﳚ
.ﹰﺎﺒﻳﺮﻘﺗ ﱰﻣ ﻦﺗﻮﻴﻧ
ﺐﻴﻘﺜﺗ ﺔﻟﺁ
GBM 6 RE
Professional
GBM 6 RE
Professional
ﯽﺼﻗﻷﺍ ﺐﻴﻘﺜﺘﻟﺍ Ø
ﺫﻻﻮﻓ –
ﺐﺸﺧ –
ﻡﻮﻴﻨﳌﺃ –
ﻢﻣ
ﻢﻣ
ﻢﻣ
6,5
15
8 6,5
15
8
ﺏﺎﻘﺜﳌﺍ ﻑﺮﻇ ﺪﺷ ﻝﺎﳎ ﻢﻣ 1 – 10 1,5 – 10
EPTA-Procedure 01/2003 ﺐﺴﺣ ﻥﺯﻮﻟﺍ ﻎﻛ 1,2 1,2
ﺔﻳﺎﻗﻮﻟﺍ ﺔﺌﻓ
II / II /
.ﺔﻨﻴﻌﻣ ﻥﺍﺪﻠﺒﺑ ﺔﺻﺎﺧ ﺕﺍﺯﺍﺮﻄﺑ ﻭﺃ ﻚﻟﺫ ﻦﻋ ﺪﻬﳉﺍ ﻒﻠﺘﳜ ﺎﻣﺪﻨﻋ ﻢﻴﻘﻟﺍ ﻩﺬﻫ ﺕﻭﺎﻔﺘﺗ ﺪﻗ .ﻂﻟﻮﻓ 230 ﺭﺍﺪﻘﻤﺑ [U] ﻲﻤﺳﺍ ﺪﻬﳉ ﻝﻮﻌﻔﳌﺍ ﺔﻳﺭﺎﺳ ﻢﻴﻘﻟﺍ
.ﺓﺩﺮﻔﳌﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ ﺾﻌﺒﻟ ﺔﻳﺭﺎﺠﺘﻟﺍ ﺕﺎﻴﻤﺴﺘﻟﺍ ﻒﻠﺘﲣ ﺪﻗ .ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻚﺗﺪﻋ ﺯﺍﺮﻃ ﺔﺘﻓﻻ ﯽﻠﻋ ﻒﻨﺼﻟﺍ ﻢﻗﺭ ﺓﺎﻋﺍﺮﻣ ﯽﺟﺮﻳ
