ASRock H61M/U3S3 Motherboard
Motherboard Layout
English
1
Power Fan Connector (PWR_FAN1)
15
USB 2.0 Header (USB8_9, Blue)
2
1155-Pin CPU Socket
16
SATA2 Connector (SATA2_2, Blue)
3
CPU Fan Connector (CPU_FAN1)
17
SATA2 Connector (SATA2_3, Blue)
4
ATX 12V Power Connector (ATX12V1)
18
Consumer Infrared Module Header (CIR1)
5
2 x 240-pin DDR3 DIMM Slots
19
USB 2.0 Header (USB6_7, Blue)
(Dual Channel: DDR3_A1, DDR3_B1, Blue)
20
System Panel Header (PANEL1, White)
6
Chassis Speaker Header (SPEAKER 1, White) 21
Infrared Module Header (IR1)
7
ATX Power Connector (ATXPWR1)
22
Clear CMOS Jumper (CLRCMOS1)
8
SATA3 Connector (SATA3_0, White)
23
COM Port Header (COM1)
9
SATA3 Connector (SATA3_1, White)
24
Print Port Header (LPT1, White)
10
Intel H61 Chipset
25
PCI Express 2.0 x1 Slot (PCIE2, White)
11
Chassis Fan Connector (CHA_FAN1)
26
Front Panel Audio Header
12
32Mb SPI Flash
(HD_AUDIO1, White)
13
SATA2 Connector (SATA2_0, Blue)
27
PCI Slots (PCI1-2)
14
SATA2 Connector (SATA2_1, Blue)
28
PCI Express 2.0 x16 Slot (PCIE1, Blue)
Intel
H61
H61M/U3S3
A
T
XPWR1
Designed
in
T
aipei
21.8cm (8.6 in)
24.4cm
(9.6
in)
DDR3_A1
(64
b
it,
2
40-pin
module)
DDR3_B1
(64
bit,
240-pin
module)
Dual
Channel
D
DR3
PCIE1
PCI1
PCI2
Top:
RJ-45
USB 2.0
T: USB4
B: USB5
PS2
Keyboard
VGA1
DVI_CON1
HDMI1
USB 2.0
T: USB0
B: USB1
T
op:
LINE
IN
Center:
FRONT
Bottom:
MIC
IN
Super
I/O
CMOS
Battery
ATX12V1
DX10.1
PWR_F
AN1
CPU_FAN1
PCI
E
xpress
2.0
ErP/EuP Ready
LAN
PHY
1
HD_AUDIO1
AUDIO
CODEC
COM1
1
RoHS
IR1
1
USB6_7
1
CIR1
1
CLRCMOS1
1
32Mb
BIOS
1
SATA2_3
SATA3_1
SATA3_0
HDLED RESET
PLED PWRBTN
PANEL1
1
SPEAKER1
CHA_F
AN1
1
LPT1
Gigabit
LAN
1
2
3
4
5
6
11
12
13
14
10
7
8
9
16
15
17
18
24
19
20
21
22
23
25
26
27
28
SATA2_2
PS2
Mouse
USB 3.0
T: USB2
B: USB3
SATA2_1
SATA2_0
USB8_9
1
PCIE2
