6
ASRock Z68 Extreme4 Motherboard
English
1.2 Specifications
Platform - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
- All Solid Capacitor design (100% Japan-made high-quality
Conductive Polymer Capacitors)
CPU - Supports 2nd Generation Intel ® Core TM i7 / i5 / i3 in
LGA1155 Package
- Advanced V8 Power Phase Design
- Supports Intel ® Turbo Boost 2.0 Technology
- Supports K-Series unlocked CPU
- Supports Hyper-Threading Technology (see CAUTION 1)
Chipset - Intel ® Z68
Memory - Dual Channel DDR3 Memory Technology (see CAUTION 2)
- 4 x DDR3 DIMM slots
- Supports DDR3 2133(OC)/1866(OC)/1600/1333/1066
non-ECC, un-buffered memory (see CAUTION 3)
- Max. capacity of system memory: 32GB (see CAUTION 4)
- Supports Intel ® Extreme Memory Profi le (XMP)
Expansion Slot - 3 x PCI Express 2.0 x16 slots (PCIE2/PCIE4: single at x16
or dual at x8/x8 mode; PCIE5: x4 mode)
- 2 x PCI Express 2.0 x1 slots
- 2 x PCI slots
- Supports ATI TM Quad CrossFireX TM , 3-Way CrossFireX TM
and CrossFireX TM
- Supports NVIDIA ® Quad SLI TM and SLI TM
Graphics * * Requires Processor with Intel ® Graphics Technology
- Intel ® HD Graphics 2000/3000
- Pixel Shader 4.1, DirectX 10.1
- Max. shared memory 1759MB (see CAUTION 5)
- Four VGA Output options: D-Sub, DVI-D, HDMI and
DisplayPort (see CAUTION 6)
- Supports HDMI 1.4a Technology with max. resolution up to
1920x1200 @ 60Hz
- Supports DVI with max. resolution up to 1920x1200 @ 60Hz
- Supports D-Sub with max. resolution up to 2048x1536 @
75Hz
- Supports DisplayPort with max. resolution up to 2560x1600
@ 60Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI
(Compliant HDMI monitor is required) (see CAUTION 7)
