ASRock E35LM1 Motherboard
Motherboard Layout
English
1
CPU Fan Connector (CPU_FAN1)
13
Chassis Speaker Header
2
Chassis Fan Connector (CHA_FAN1)
(SPEAKER 1, White)
3
CPU Fan
14
Chassis Fan Connector (CHA_FAN2)
4
CPU Heatsink
15
32Mb SPI Flash
5
2 x 240-pin DDR3 DIMM Slots
16
PCI Express 2.0 x16 Slot (PCIE1, Blue)
(DDR3_A1, DDR3_A2, Blue)
17
Consumer Infrared Module Header (CIR1)
6
Clear CMOS Jumper (CLRCMOS1)
18
USB 2.0 Header (USB8_9, Blue)
7
ATX Power Connector (ATXPWR1)
19
USB 2.0 Header (USB6_7, Blue)
8
System Panel Header (PANEL1, White)
20
Front Panel Audio Header
9
SATA3 Connector (SATA3_4, White)
(HD_AUDIO1, White)
10
SATA3 Connector (SATA3_2, White)
21
COM Port Header (COM1)
11
SATA3 Connector (SATA3_3, White)
22
AMD A50M Chipset
12
SATA3 Connector (SATA3_1, White)
SPEAKER1
1
PANEL 1
HDLED RESET
PLED PWRBTN
1
CMOS
Battery
32Mb
BIOS
