ASRock 960GM-VGS3 FX / 960GM-VS3 FX Motherboard
English
Motherboard Layout
1
ATX 12V Power Connector (ATX12V1)
12
SATA2 Connector (SATAII_2 (PORT 2))
2
CPU Heatsink Retention Module
13
SATA2 Connector (SATAII_1 (PORT 1))
3
AM3+ CPU Socket
14
Southbridge Controller
4
2 x 240-pin DDR3 DIMM Slots
15
PCI Slot (PCI1)
(Dual Channel: DDR3_A1, DDR3_B1)
16
USB 2.0 Header (USB8_9)
5
CPU Fan Connector (CPU_FAN1)
17
USB 2.0 Header (USB6_7)
6
ATX Power Connector (ATXPWR1)
18
Clear CMOS Jumper (CLRCMOS1)
7
SATA2 Connector (SATAII_4 (PORT 6))
19
Chassis Intrusion Header (CI1)
8
Northbridge Controller
20
SPI Flash Memory (8Mb)
9
Chassis Fan Connector (CHA_FAN1)
21
PCI Express 2.0 x16 Slot (PCIE1)
10
SATA2 Connector (SATAII_3 (PORT 5))
22
Front Panel Audio Header (HD_AUDIO1)
11
System Panel Header (PANEL1)
Super
I/O
CMOS
BATTERY
A
TXPWR1
AMD
760G
Chipset
PCI1
LAN
AUDIO
CODEC
1
CLRCMOS1
CPU_FAN1
HDLED
RESET
PLED
PWRBTN
1
PANEL 1
HD_AUDIO1
1
RoHS
5
6
1
2
3
4
7
9
10
11
12
13
14
15
16
17
18
19
20
21
22
8Mb
BIOS
AMD
SB710
Chipset
SA
T
AII_4
(PORT
6)
USB8_9
1
USB6_7
1
PCIE1
DDR3
1866
Top:
LINE
IN
Center:
FRONT
Bottom:
MIC
IN
PS2
Mouse
PS2
Keyboard
USB 2.0
T: USB0
B: USB1
Top:
RJ-45
USB 2.0
T: USB2
B: USB3
FSB800
DDR3_A1
(64
bit,
240-pin
module)
DDR3_B1
(64
bit,
240-pin
module)
Support
8-Core
CPU
ErP/EuP Ready
VGA1
ATX12V1
8
SOCKET
AM3b
SA
T
AII_3
(PORT
5)
SA
T
AII_2
(PORT
2)
SATAII_1 (PORT 1)
CHA_FAN1
CI1
1
X
Fast
RAM
X
Fast USB
X
Fast
LAN
