Page 2
2
ASRock H61M-VG3 / H61M-VS3 Motherboard
Motherboard Layout
English
1
32Mb SPI Flash
11
Power LED Header (PLED1)
2
SATA2 Connector (SATA_1 (PORT 1))
12
System Panel Header (PANEL1)
3
SATA2 Connector (SATA_0 (PORT 0))
13
Chassis Fan Connector (CHA_FAN1)
4
SATA2 Connector (SATA_2 (PORT 4))
14
Chassis Intrusion Header (CI1)
5
SATA2 Connector (SATA_3 (PORT 5))
15
PCI Express 3.0 x16 Slot (PCIE2)
6
USB 2.0 Header (USB6_7)
16
PCI Express 2.0 x1 Slot (PCIE1)
7
USB 2.0 Header (USB4_5)
17
Front Panel Audio Header (HD_AUDIO1)
8
ATX Power Connector (ATXPWR1)
18
1155-Pin CPU Socket
9
2 x 240-pin DDR3 DIMM Slots
19
CPU Fan Connector (CPU_FAN1)
(Dual Channel: DDR3_A1, DDR3_B1)
20
ATX 12V Power Connector (ATX12V1)
10
Clear CMOS Jumper (CLRCMOS1)
21
Intel H61 Chipset
DDR3_A1
(64
bit,
2
40-pin
module)
DDR3_B1
(64
bit,
240-pin
module)
Intel
H61
PCIE2
AUDIO
CODEC
32Mb
BIOS
ATXPWR1
ATX12V1
1
USB6_7
HDLED RESET
PLED PWRBTN
PANEL1
CLRCMOS1
1
PLED1
1
1
CHA_FAN1
CPU_FAN1
1
HD_AUDIO1
SATA_1 (PORT 1)
SATA_0 (PORT 0)
SATA_2 (PORT 4)
1
USB4_5
SATA_3 (PORT 5)
CMOS
BATTERY
PCIE1
LAN
CI1
1
PS2
Keyboard
PS2
Mouse
VGA1
USB 2.0
T: USB0
B: USB1
Top:
RJ-45
USB 2.0
T: USB2
B: USB3
T
op:
LINE
IN
Center:
FRONT
Bottom:
MIC
IN
DDR3
X
Fast
RAM
X
Fast USB
X
Fast LAN
RoHS
1 2
3
4
5
6 7
10
8
9
11
12
14
13
15
16
17
18
19
20
21
