User’s Manual
Page 8
EN
Projecting from External AV Source
AV IN
Follow the figure below to connect the external AV output device to the AV jack
near the speaker. Connection is color-coded. After connection, the screen
switchs to AV source automatically.
Note: AV-IN cable is optional.
HDMI
Use the HDMI cable to connect the HDMI port on the rear panel of the projector
to the external HDMI signal source. After connection, the screen switchs to
HDMI source automatically.
Note: Most video content are at 16:9 ratio. USB “Menu Button” to select among
three projection modes to optimized the visual quality.
Illustration for the three kinds of Projection Mode:
Smartphone
(Source)
Screen
16:9 Aspect Ratio
Projection
Screen
Pan & Scan (4:3) Letterbox (16:9) Theme mode (4:3)
