3. PARTS INTRODUCTION
PARTS DESCRIPTION
1
. Control panel 2. Basket 3. Charger Socket
4. Tiller Adjustment Knob 5. Seat 6. Seat Rotation Lever
7. Battery Pack 8. Freewheel Lever 9. Anti-tip wheels
10. Seat Post Knob 11. Seat Height Adjustment Pin
