Acnodes RK 121 - Manual (Page 3)

RK121
1U Rackmount Keyboard Drawer
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com. 14628 Central Ave,
Chino, CA 91710
tel:909.597.7588, fax:909.597.1939
Contents
RK121
1.1 Package Content
1.2 Structure Diagram & Dimension
1.3 Installation
P.1
P.1 - 2
P.3
< Part. 2 > Specifications
2.1 Keyboard / Mouse Specifications P.4 - 6
< Part. 3 > KVM Integration
htt p:// www. acnodes.com/files/downloads/CMKVM-UM.pdf
Matrix
Cat6 KVM
Local Remote IP 16-port 32-port
1 1 1 MKCP1613 MKCP3213
1 1 2 MKCP1624 MKCP3224
1 1 0 MKCS1602 MKCS3202
1 2 0 MKCS1603 MKCS3203
1 3 0 MKCS1604 MKCS3204
htt p:// www. acnodes.com/files/downloads/CKVM-UM.pdf
Combo
Cat6 KVM
Local Remote IP 8-port 16-port 32-port
1 0 1 KCP802 KCP1602 KCP3202
1 1 0 KC802 KC1602 KC3202
1 0 0 KC801 KC1601 KC3201
