PMW 6460

46” Open Frame Widescreen LCD Monitor

< 1.2 > Structure Diagram - PMW 6460

1

Front view

2

OP-W46

4

3

6

Bottom view

1

Rear case

2

LCD panel

3

Universal open frame mounting

4

Audio speaker, pair

5

LCD membrane

6

Extended remote sensor membrane cable

( 66cm from AD board to sensor end )

5

Rear view

Model

Product Dimension

(W x D x H)

Packing Dimension

(W x D x H)

Net

Weight

Gross

Weight

PMW6460

1121 x 82 x 676 mm

44 x 3.2 x 26.6 inch

1457 x 216 x 920 mm

57.4 x 8.5 x 36.2 inch

50 kg

110 lbs

65 kg

143 lbs
