MKDH8170C/8190C
1U Rackmount LCD Keyboard Drawer
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com. 14628 Central Ave,
Chino, CA 91710
tel:909.597.7588, fax:909.597.1939
Contents
< Part. 2 > MKDH8170C/8190C
1.1 Package Content
1.2 Structure Diagram & Dimension
1.3 Installation
P.1
P.1 - 2
P.3 - 5
< Part. 2 > Specifications / OSD
2.1 Product Specifications
2.2 Keyboard / Mouse Specifications
2.3 On-screen Display Operation ( OSD )
P.6 - 7
P.8
P.9 - 10
< Part. 3 > Options
3.1 Audio
3.2 48V, 24V or 12VDC power
< Part. 4 > KVM Integration
http://www.acnodes.com/files/downloads/CKVM-UM.pdf
P.11
P.12
Combo
Cat6 KVM
Local Remote IP 8-port 16-port 32-port
1 0 1 KCP802 KCP1602 KCP3202
1 1 0 KC802 KC1602 KC3202
1 0 0 KCS801 KC1601 KC3201
