< 1.4 > Connection to PS/2 or USB Server
LCD console drawer LCD console drawer
Power KVM Power KVM
Combo
KVM cable
Combo
KVM cabl
PS/2 server USB server
LCD console drawer LCD console drawer
Power KVM Power KVM
Combo
KVM cable
PS/2 console KVM
Caution : The LCD console drawer is hot-pluggable, but components of connected devices, such
as the ser vers and KVM switch, may not be hot-pluggable. Plugging and unplugging cables while
server s and KVM are powered on m ay cause irrevers ible damage to the servers, KVM and LCD
console drawer. Before attempting to connect anything to the LCD console drawer, we suggest
turning off the power to all devices. Apply power to connected devices again only after the LCD
console drawer is receiving power. The company is not responsible for damage caused in this way.
