RPQ 1190

1U 19” 1280x1024 Rackmount CCTV Monitor

<

<

< Part 1 >

< 1.1 > Package Content

RPQ 1190 unit X 1

- 6ft VGA cable X 1
- Pow er cord X 1

- M6 screw, cage nut & cup w asher X 8

The above package content is only for the pure

model ( VGA only ). It varies with options such as

DC power.

< 1.2 > Structure Diagram

1

2

3

4

5

1

LCD panel

2

Installation Slid e

3

LCD OSD membrane

4

Quad display control membrane

5

Thumb Screw
