Page 15: 3 > qd remote control connection & operation
14628 Central Ave,
Chino, CA 91710
tel:909.597.7588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at .
RPWQ 1190
1U 19” 1440x900 Rackmount CCTV Monitor
< 4.3 > QD Remote Control Connection & Operation
Rear Panel
RS-232
h i - z
1 2 3 4
IN
OUT
dc 12V, 1amp ALARM I/O
75
monitor
vcr
RS-232 Cable Wire
Computer
Remote Keypad
