Acnodes MKD 6117U User Manual
Page 3
MKD6117U
1U Rackmount LCD Keyboard Drawer
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
14628 Central Ave,
Chino, CA 91710
tel:909.597.7588, fax:909.597.1939
Contents
< Part. 1 >
MKD6117U
1.1
Package Content
1.2
Structure Diagram & Dimension
1.3
Installation
< Part. 2 >
Specifications / OSD
2.1
Product Specifications
2.2
Keyboard / Mouse Specifications
2.3
On-screen Display Operation ( OSD )
2.4
Picture In Picture ( PIP ) / Picture By Picture ( PBP )
< Part. 3 >
Options
3.1
Audio
3.2
48V, 24V or 12VDC power
< Part. 4 >
KVM Integration
