RP1205
1U 20” Industrial Rackmount LCD Monitor
< Part 1 >
< 1.1 > Package Content
RP1205 unit X 1
- 6ft VGA cable X 1
- Power cord X 1
- M6 screw, cage nut & cup washer X 8
The above package content is only for the pure model ( VGA and DVI-D only ).
It varies with options such as HDMI, AV, audio & DC power.
< 1.2 > Structure Diagram
1
2
4
3
5
6
1 LCD panel
2 Installation Slide
3 LCD OSD membrane
4 Audio speaker
5 Carry handle to release the 2-pt lock
6 2-point lock
