RMW 7194
19” 1000-nit High Brightness Widescreen LCD
7U Rackmount Display Panel
< Part 1 >
< 1.1 > Package Content
R MW71 94 unit X 1
- 6ft VGA cable X 1
- Power adapter X 1
- Power cord X 1
< 1.2 > Structure Diagram
Front view
2
1
3
Po wer ada pter
R ear view
3
1 LCD panel
2 LCD membrane
3 Audio speaker
4 Power adapter basket
P owe r cord
DVI-D
Audio
Power BNC S-Video VGA H DM I
S tandard
AV2.2D upgrade
AV2.2H upgrade
O ption
out - in - in
Video PC
: DVI-D + VGA
: DVI-D + VGA + BNC + S-V ideo + audio
: HDMI + VGA + BNC + S-V ideo + audio
: SDI, USB for touchscreen & DC power
