PM 6104
10.4” Industrial Open Frame Monitor
< 1.2 > Structure Diagram-PM 6104 10.4" LCD Display
1
Front view
2
OP-10
3
Rear view
1 Rear case
2 LCD panel 4
3 Audio speaker ( for Audio or TV option )
5
4 Universal open frame mounting
5 LCD membrane
Model
Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
PM6104
282 x 57 x 219 mm
11.1 x 2.2 x 8.6 inch
515 x 117 x 429 mm
13.5 x 2.5 x 10 inch
2.5 kg
5.5 lbs
4.5 kg
9.9 lbs
