PM 6190
19” Industrial Open Frame Monitor
P.1
UM-UV-19-Q312V2 www.austin-hughes.com
< 1.2 > Structure Diagram -PM 6190 19" LCD Display
1
Front view
2
OP-19
3
1 Rear case
2 LCD panel
3 Audio speaker ( for HDMI, Audio or TV option )
4 Universal open frame mounting
5 LCD membrane
6 Extended remote sensor membrane cable
( 66cm from AD board to sensor end )
6
Rear view
4
5
Model
Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
PM6190
474 x 58 x 381 mm
18.6 x 2.3 x 15 inch
651 x 124 x 597 mm
25.6 x 4.9 x 23.5 inch
6 kg
13 lbs
8 kg
18 lbs
