KD 8176

1U rack mount LCD keyboard drawer

1.3 Specifications

Material:
Heavy-duty steel

LCD Panel:
Size: 17"
Brightness (cd/m^): 300cd/m^
Pixel Pitch:0.264(H) x 0.264(V)mm
Contrast Ratio: 1000:1
Response time: Tr=1.3ms/Tf=3.7ms
Viewing Angle: 160 °(L/R),160°(U/D)
Colors: 16.7M colors
MTBF: 50,000 hours

On Screen Display Control:
Brightness, Contrast, Phase & Color, H &V position, Auto-
tune, Recall & Language

Video Input:
VGA, Analog RGB (standard)
Optional for S-Video & Composite (RCA) / S-Video & BNC /
DVI-D

Front Panel Controls :
Power on/off switch
OSD(on screen display)

Connectors:
1 x Console port (HD 15 female)
1 x DC power input (Plug-round type)

Cable:
1 x 6-ft KVM cable
Optional for PS/2 or USB KVM Cables & Cascade cables in
various length

LCD Drawer & KVM Benefits:
Short Depth design of 18.9" only
Depth will fit 23.6" rack application

Touch Screen(Optional) :
Capacitive type touch screen or Resistive type touch screen

Resolutions:
1280 x 1024 with 60/ 70/ 75Hz

Power Supply:
110/220 V AC Input, 12V 5A Output
Adapter Size: 4.3"(L) x 2.4"(W) x 1.2"(H)
Optional DC power with 48V/ 24V/ 12V DC input

Keyboard and touch pad :
104-key Keyboard w/ 2-button touch pad (combo free)

Color:
Black

Environmental:
Temperature:
Operate 0°~ 50°C
Storage-25°~ 65°C
Humidity: 90% RH
Shock: 50G peak acceleration, (11ms, half since wave)
Vibration: 58~500Hz/0.98G (11min/cycle)

Safty:
CE, FCC, VCCI

Compatibility:
Multi-platform - Mix PCs, SUNs, IBMs, HPs & DELLs

Gross Weight:
15kg / 33lb

Dimension:
17.3"(W) x 1.75”(H) x 18.9"(D)
