< 3.2 > Options : Touchscreen & driver
17
” / 19" U SB Touchscreen Speci fication
M odel
Technology
Touch Point
M ethod
Activation Force
Durability Response
Time Optical
Transmittance
Surface Hardness
Haze
Glass
Connector
Compatibility
17
’
19
”
17
”
19
”
TRB e-Resistive TCB e-Capacitive
5-W ire Resistiv e Capacitive
Single Single
Stylus or Finger Finger
= 50g / Stylus=R0.8 = 50g
35 million touches 300 million touches
15 ms 20 ms
80% ± 3% 93% ±2%
3H 9H
8% ± 3% 7%
1.4 ±0.2 mm 3.2 ±0.2 mm 2.8 m m ±10% 2.8 mm ±10%
USB Type A USB Type A
W indows 7 / XP / Vista, Linux W indows 7 / XP / Vista, Linux
¦
USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc
¦
For detailed information, please refer to the attached CD disc
¦
As the touchscreen unit is not made of toughened glass, please handle it carefully
USB Touchscreen
Power
KV M
Please follow the below steps to setup the touch screen:-
Step 1. Run the bundled CD disc
Step 2. Double click the Setup.exe
Step 3. Follow the installation instruction to finish the s etup
Step 4. After installation, run the TouchKit program & the “4 point calibration”
Please do the initial calibration
after the first setup
