Acclaim Lighting Color Ray ND - Manual (Page 2)

Control:
1 = Not Applicable
Color Ray ND (IP65)
System
Max. in Chain
Cabling System
Control
DMX Channels
Addressing DMX
Power requirements
LED Current
Light Source
Power Consumption
Weight
Housing
Listing
Source Life
Operating Temp.
Storage Temp.
Including
24Vdc
8 pcs
5-Pin IP67 Waterproof Conn.
-
-
-
24Vdc
500mA
3 x CREE 3W XRE LED
9,3W
1,2 kg
Die Cast Aluminium with powder coating
CE Certified
50.000 hours at 70% lumen maintenance
-20 °C ~ +50 °C
-20 °C ~ +70 °C
20 cm 5-pin WP input and output cable
- x x x - x x x x
Version:
N = Normal
Color:
A
C
E
G
N
P
Q
R
S = WW 2700k
= WW 3200k
= NW 4000k
= CW 6000k
= Red
= Green
= Blue
= Amber
= Special
Beam angle:
C
F
H = 10°
= 25°
= 40°
LED Config:
A = 3 LEDs
Cover:
1= Clear
Housing:
1= Black Color
2= White Color
CRB
147mm [5.8 in]
334mm [13.2 in]
89mm [3.5 in]
100mm [3.9 in]
163mm [6.4 in]
Outdoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
ACCLAIM
LIGHTING
+24V GND
l D M X l D-
GND
D+
max. 8pcs. in a chain
5 pin WP first cable
standard 2m
5 pin WP
link cable optional
24V DC
NC
Color Ray ND
Wiring diagram
