Acclaim Lighting AL Spot IP65 - Manual (Page 2)

Control:
1 = Not Applicable
AL Spot (IP65)
System
Max. in Chain
Cabling System
Control
DMX Channels
Addressing DMX
Power requirements
LED Current
Light Source
Power Consumption
Weight
Housing
Listing
Source Life
Operating Temp.
Storage Temp.
Including
Constant Current (6-Wire)
1 pc
6-wire DC
AL Power HP 12RGB (12 x RGB 700mA)
Controled by 3 DMX Channels
-
-
700mA Max
3 x Rebel LED (3W)
9W
0,6 kg
Die Cast Aluminium with powder coating
CE Certified
50.000 hours at 70% lumen maintenance
-20 °C ~ +50 °C
-20 °C ~ +70 °C
5 m cable and 6-pin terminal connector(s)
- x x x - x x x x
Version:
N = Normal
Color:
A
E
G
H
M
N
P
Q
R = WW 2700k
= NW 4000k
= CW 6000k
= RGB
= WW-CW-WW
= Red
= Green
= Blue
= Amber
Beam angle:
A
C
F
H = Open beam
= 10°
= 25°
= 40°
LED Config:
A = 3 LEDs
Cover:
1= Clear
Housing:
1= Black Color
2= White Color
ASC
72mm [2.8 in]
89mm [3.5 in]
74mm [2.9 in]
114mm [4.5 in]
55mm [2.2 in]
Outdoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
ACCLAIM
LIGHTING
standard 5m (16.4 ft) cable &
6 pin terminal connector
max. 12pcs. AL Spot IP65 per AL Power HP 12RGB 700mA
AL Power HP 12RGB
700 mA
DMX 512 in
DMX 512 out
100 / 240V AC in
AL Spot IP65
1 2 3 4 11 12
Wiring diagram
