FMR-5000-C en 23
Bosch Sicherheitssysteme GmbH F.01U.258.926 | 3.0 | 2012.09
Address Setting and Configuration
1.
Assign a unique physical address to each Panel Controller and Remote Keypad by setting
the rotary switches and write it down on the label (see Figure 13, Page 15, step 1 and 2).
2. For configuration, set the 6-pin DIP switch (see Figure 13, Page 15, step 3).
3. Mark the setting on the provided label (step 4).
Technical Data
CAUTION!
If Ethernet networking is planned, the Remote Keypad must be grounded.
LCD Ddisplay / touch screen LCD display with 320 x 240 pixels, touch screen with
127,5 mm x 170 mm active surface
Operating and display elements 22 buttons, 1 key switch, 11 LEDs, 1 Reboot button
Interfaces CAN1, CAN2, ETH1, ETH2, USB, RS232
Signal inputs IN1/IN2
Permissable length of CAN cable for system
networking L
max
= 1000 m, depending on configuration, cable type and topology
Power supply connection DC1 (power supply), DC2 (redundant power supply)
Input voltage 12 V DC to 30 V DC, from FPA-5000 or FPP-5000
Maximum line restance of power supply 18 Ω
Maximum current consumption - Standby operation: 140 mA at 24 V DC
- During an alarm: 230 mA at 24 V DC
Permissible operating temperature -5 °C to +50 °C
Permissible storage temperature -20 °C to +70 °C
Housing material and color ABS plastic, light gray (similar RAL 7035)
Dimansions (H x W x D) 280 mm x 340 mm x 87 mm
Weight Approx. 3 kg
