Functional Description
The FLM-420-RLE-S is fitted with a low voltage relay for connecting one extinguishing system to one LSN fire panel.
Two feedback lines (FB1 and FB2) allow the FLM-420-RLE-S to signal a fault or the activation of the extinguishing
system. On the FLM-420-RLE-S, the fault is indicated by the yellow LED and the activation by the red LED.
The feedback lines can also be used as independent input lines for the supervised monitoring of different
peripherals.
Connections
Address Setting
With a slotted screwdriver, turn the rotary switches in the required positions (Figure 9, Page 8).
Technical Specifications
NOTICE!
The installation must only be performed by authorized and specialized personnel!
Designation Connection
NO | COM Relay, control of extinguishing system
b1+ | a- | b2+ LSN
FB2 + Feedback +, activation of extinguishing system
FB1- | FB2- Feedback -, fault / activation of extinguishing system
FB1+ Feedback +, fault of extinguishing system
Address (A) Operating mode
0 0 0 Loop/stub in LSN improved version mode with automatic addressing
0 0 1 - 2 5 4 Loop/stub/T-taps in LSN improved version mode with manual addressing
CL 0 0 Loop/stub in LSN classic mode (address range 127 max.)
2 5 5 - 2 9 9 Non-permitted address range (error message on fire panel)
Max. number of extinguishing systems per FLM-420-RLE-S 1
Displays 1 LED red, 1 LED yellow
Voltage range 2 V DC to 30 V DC
Input voltage 15 V DC to 33 V DC
Max. current consumption 7.9 mA
Activation extinguishing system
-
after initialization / during standby 3,3 kOhm
- during alarm 680 Ohm
Max. monitoring voltage 6 V
Max. monitoring current 1.5 mA (line short-circuit)
Housing material ABS/PC blend
Housing color signal white, RAL 9003
Material interface module PPO (Noryl)
Color interface module gray white, similar to RAL 9002
Dimensions with housing approx. 126 x 126 x 71 mm
Dimensions without housing (with DIN rail adapter) approx. 110 x 110 x 48 mm
Weight with housing approx. 390 g
Weight without housing approx. 150 g
Permitted operating temperature -20 °C to +50 °C
Permitted storage temperature -25 °C to +85 °C
Permitted relative humidity < 96 %
Protection class as per IEC 60529 IP 54
Classes of equipment as per IEC 60950 Class III equipment
