Candy CDS 155X__1-S - Manual (Page 13)

24
The water-stop device protects against water damages caused by leaks on the fill
hose which could develop due to natural ageing of the hose.
In the water-stop system the leaking water fills the corrugated hose and activates a
stop valve which cuts off the water supply to the machine.
This fault is shown by a red sector on the window «A».
Would this occur, please refer to your Service Agent.
If the hose is not long enough for correct connection, it must be replaced with a longer
one. The hose can be obtained from your Service Agent.
WATERCONTROL-SYSTEM
Red button blocked
valve indicator
Safety antitwist device
(press and twist to
remove the washer)
A
According to the degree of hardness of
your water, regulate the softener unit in the
following way:
IMPORTANT
The dishwasher must be ALWAYS
off before start this procedure.
1. When the dishwasher is off, OPEN
the door.
2. Turn the programme selector to the
"UNIVERSAL" programme position.
3. Press the "ON/OFF" button.
4. WITHIN 15 seconds, turn the dial (in a
anti-clockwise direction) to the "RESET"
position then go to the "UNIVERSAL"
programme position again, doing this
4 times (finishing with the programme
selector on the "UNIVERSAL" programme
position).
5. The indicator light "WASHING" will
flash 3 times and the alarm will sound
3 times, to indicate the factory water
softener setting (LEVEL 3).
6. Turn the programme selector to one of
the inclusive positions among 1 and 6 to
choose the required water softener level.
7. The indicator light "WASHING" will
flash and the alarm will sound some
times, according to the select level (for
example, 5 times for the LEVEL 5).
8. Turn off the dishwasher pressing the
"ON/OFF" button to confirm the new
setting.
WARNING!
If any problem occurs, turn the
dishwasher off by pressing the
"ON/OFF" button and start the
procedure again from the beginning
(STEP 1).
25
WATER SOFTENER UNIT
Depending on the source of the supply,
water contains varying amounts of limestone
and minerals which are deposited on the
dishes leaving whitish stains and marks.
The higher the level of these minerals
present in the water, the harder the water is.
The dishwasher is fitted with a water
softener unit which, through the use of
special regenerating salt, supplies
softened water for washing the dishes.
The degree of hardness of your water can
be obtained from your water supply
company.
Regulating the water softener
The softener unit can treat water with a
hardness of up to 90°fH (French grading)
or 50°dH (German grading) through 6
different settings.
The table below lists different degrees of
water hardness with the corresponding
setting for the softener unit.
* The water softener unit is set in the
factory at level 3, as this is suitable for
the majority of users.
Level
ºfH
(French grading)
ºdH
(German
grading)
NO
YES
YES
YES
YES
YES
Position 6
Position1
Position 2
Position 3
Position 4
Position 5
Water
hardness
W
ater
softener setting Use of
regenerating
salt
0
1
2
*3
4
5
0-5
6-15
16-30
31-45
46-60
61-90
0-3
4-9
10-16
17-25
26-33
34-50
Level 1
Level 2
Level 3
Level 4
Level 5
("UNIVERSAL" programme)
Level 0
