USING THE COOKTOP
Gas burners
The inflow of gas to the burners is adjusted by the knobs in fig.4 that control the taps. When the knob
pointers coincide with the symbols shown below, the following setting s are obtained:
Tap closed, no gas supply
Maximum flow, maximum gas supply
Minimum flow, minimum gas supply
Igniting the burners
This model is equipped with a safety valve which, if the bu rner goes out for any reason, automatically
interrupts the supply of gas.
To restore operation, move the knob to position and repeat the igniting operations described in the next
section.
Using burners with safety valves
o Turn the knob of the gas tap to the maximum supply position, then press and hold down for about 4 -
5 seconds.
Release the knob and adjust the flame by turning the knob until reaching the desired intensity.
o Warning:
The ignition device cannot be operated for more t han 15. If after this period the burner still has not lit,
or if it has gone out for accidental reasons, wait at least 1 minute before repeating the operation.
Burner selection
The symbol printed above each knob on the control panel (drawing in fig.4) indicates the correspondence
between knob and burner. The selection of the most suitable burner depends on the diameter and capacity
of the cookware (see table).
It is important that the pot diameter is suited to the power of the burner, in order to not compromise its high
efficiency.
Pot diameter
Burner Minimum diameter Maximum diameter
Left Auxiliary 60 mm (with reducer) 140 mm
Right Auxiliary 60 mm (with reducer) 140 mm
Right Semi -Rapid 100 mm 160 mm
Left Semi-Rapid 100 mm 180 mm
Triple Crown 200 mm 260 mm
