16 ASUS Xonar Essence STX
No Item Description
1 Support link Clicking this button will lead you to the ASUS official website.
2 Display Area This display area shows the 10-band signal meter, volume
level, and the status of the Dolby/DTS technologies, EQ, and
DSP modes. Note: this area just displays information, but is
not used to alter settings.
3 Setting Menu Panel This panel gives access to setting tabs, including Main
Settings, Mixer/volume, Effects, Karaoke, FlexBass, and
VocalFX.
4 Information icon Clicking this icon will pop up driver’s Information window.
5 Menu Open/Close Clicking this button will move the display area and reveal
the configuration area below. Clicking it again will move the
display area back down.
6 Master Volume This rotary knob controls the master playback volume. Drag
the small circle inside it to change the volume level.
7 Mute Button Click this button to mute audio playback; it will display a red
light when playback is muted.
8 SVN Button Click this button to enable the “Smart Volume Normalization”
feature for constant volume from all playback sources. It will
display a blue light when enabled.
9 DSP Mode These 4 buttons give access to quick sound effects
combinations for Music, Games, DVD Video, and effect-free
(Hi-Fi) modes.
NOTE: Default DSP Mode is OFF.
