8
FILTERING VERSION
When there is no exhaust duct for venting
outdoors, you can use a carbon filter. The
air is depurated by the filter and put again in
the surrounding. To use the appliance in this
version, proceded as follows:
- Fix the filtering fitting "D" to the bracket
"E" Fig.3
- Insert the ring "A" to the filtering fitting
"D".
- Insert a flexible duct from the fitting "F"
to the ring "A" and fix it with some small
bands.
- Open the grate;
- Insert the filter (C) using the “B” knobs
(FIG.1);
- Remount the grate;
- To convert the hood from “vented” to
“filtering,” contact the retailer or the
manufacturer for the kit needed for
installation.
INSTALLING THE CHIMNEY
- Fasten the “E” bracket (Fig. 1), located
on the perpendicular part of the outlet
hole on the hood, at the highest point on
the wall next to the ceiling, using the two
Ø 8 mm screws and wall anchors
provided.
- Make the chimney with slits run inside
the other chimney
- Fix the chimney with slits turned up to
the bracket "E" using the two screws
supplied with the hood; put the other
chimney on the upper part of the hood
and fix it using the 2 screws supplied
with the hood.
INSTALLATION FIG.4
- Once installed, the appliance must be
no less than 65 cm away from an electric
hob and no less than 65 cm away from
gas burners or a mixed hob.
- If the instructions for the installation of
the gas cooking appliance specify a
greater distance, please take this into
account.
Electrical Connection
The electrical tension must correspond to
the tension noted on the label placed inside
the cooker hood. Connect the electrical plug,
where provided, to the an easily accessible
outlet in conformity with local standards in
force.
Where an electrical plug is not provided (for
direct connection to electrical network) place
a standards approved bipolar switch with an
aperture distance of not less than 3mm
(accessible) from the contacts.
USE
The hood is designed to be used to either
filter and re-circulate air, or as a vented
appliance.
FASTENING THE COOKER HOOD
TO A WALL FIG.2
- Place the template in the centre and
make the relative holes.
- Insert the dowels into the wall
- (cm 90-120 Hang the hood onto the 2
screws through the outlined slots and
screw these down tightly).
- Block the hood definitively using screws
and washers.
- The screws and dowels are provided with
the appliance.
SUCTION FUNCTION
To utilize this function you have to provide
with a flexible duct Ø120/150 mm. to
connect to the fitting "F" Fig.3 , that must be
subsequently fixed to the ceiling.
GB
