Page 13
300Mbps Wireless N Router
TL-WR940N/TL-WR941ND
-5-
1.4.2
The Rear Panel
Figure 1-2 Rear Panel sketch
The following parts are located on the rear panel (View from left to right).
¾
1,2,3,4 (LAN): These ports (1, 2, 3, 4) connect the router to the local PC(s).
¾
WAN: This WAN port is where you will connect the DSL/cable Modem, or Ethernet.
¾
WPS/RESET: This button is used for both WPS and Reset function. To use the WPS function,
press it for less than five seconds; to use the RESET function, press it for more than five
seconds.
¾
ON/OFF: the switch for the power.
¾
POWER: The Power socket is where you will connect the power adapter. Please use the
power adapter provided with this TL-WR941ND 300Mbps Wireless N Router.
¾
Wireless antenna: To receive and transmit the wireless data.
