SERVICE INFORMATION SHR-150SI
2
1 SERVICE INFORMATION
1-1 Specifications
Dimensions Length* mm(in) 310 (12.2)
Width* mm(in) 375 (14.8)
Height* mm(in) 550 (21.7)
Dry weight* kg(lb) 5.6 (12.3)
Engine Type KIORITZ, air-cooled, two-stroke, single cylinder
Rotation Counterclockwise as viewed from the output end
Displacement cm 3 (in 3 ) 21.2 (1.29)
Bore mm(in) 32.2 (1.268)
Stroke mm(in) 26.0 (1.024)
Compression ratio 6.6
Carburetor Type Diaphragm, horizontal-draft, with primer
Model RB-K69
Ignition Type CDI (Capacitor discharge ignition) system
Spark plug BPMR7A
Starter Type i-start
Rope diameter x length mm(in) 3.0 x 1300 (0.12 x 51.2)
Fuel Type Premixed two-stroke fuel
Recommended 2-stroke engine oil ISO-L-EGD (ISO/CD13738)
Tank capacity L (U.S.fl.oz.) 0.5 (16.9)
Chemical tank capacity L (U.S.gal) 15.0 (4.0)
Clutch Type Centrifugal, 2-shoe slide
Pump Type Rotary (Regenerative)
Impeller diameter mm(in) 58.0 (2.28)
Pressure kgf/cm 2 (psi) 8 - 10 (114 - 142)
Discharge L/min(U.S.gal/min) 8.0 (2.11)
Suction hose inner dia. mm(in) 10.0 (0.39)
Return hose inner dia. mm(in) 7.0 (0.28)
Spraying hose inner dia. mm(in) 7.5 (0.30)
Spraying hose length m(ft) 1.2 (3.94)
* Without spraying hose and nozzle.
