Front and Back Panel Overview
5 Specifications Are Subject To Change Without Notice
Remote Sensor Input
Channel Status LEDs
Auto Sensing
24dB/Oct
Lowpass
With Bypass
Removable
AC Power
Supply Cord
Individual Channel
Gain Controls
0-20 MS.Phase Delay
0°-180° Phase Shift
24dB/Oct
Switchable
Subsonic Filter
WE RECOMMEND
THE ON POSITION
20, 30 and 40Hz
Room Equalization
With 12dB range
and Boost
Required LFE Inputs
Use One Only
PHASE SHIFT
0° 180°
1
RCA
XLR
SPK
2
RCA
XLR
SPK
GAIN 1 GAIN 2
PHASE DELAY
0 20ms
SUBSONIC
CORRECTION
ON OFF
ON OFF
20Hz
-6dB +6dB
30Hz
-6dB +6dB
40Hz
-6dB
110-120VAC ON
+6dB
OFF
POWER
110-120V ~ /60Hz
220-240 ~ /50Hz
600W
CROSSOVER
-40Hz 200Hz
ON BY PASS
AUTO
IR INPUT
220-240VAC
POWERED SUBWOOFER
CAUTION VORSICHT
V O R D E M Ö F F N E N
NETZSTECKER ZIEHEN BEFORE OPENING
PULL MAIN PLUG
RCA Inputs
XLR Inputs
Speaker Level Input
Fuse box
SuperNova MKVI
Subsonic Filter
Room Equalization
Lowpass filter with Bypass
Auto Sensing
Remote Sensor Input
Individual Channel Gains
Channels Status LEDs
RCA Inputs
XLR Inputs
Speaker Level Inputs
