7
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
f) keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc., in
accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
5) SERVICE
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
SAFETY INSTRUCTIONS FOR MIXERS
• Always check that the supply voltage is the same as the
voltage indicated on the nameplate of the tool
• Never use the tool in or near an explosive atmosphere
• Never mix combustible substances
• Never reach with your hand or any other object into the
mixing container during mixing
• Wear protective gloves 4, a dust mask 5, close-fitting
clothes and sturdy shoes
• The noise level when working can exceed 85 dB(A);
wear ear protection 6
• SKIL can assure flawless functioning of the tool only
when original accessories are used
• Always disconnect plug from power source before
making any adjustment or changing any accessory
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
• Do not connect the blue (= neutral) or brown (= live) wire
in the cord of this tool to the earth terminal of the plug
• If for any reason the old plug is cut off the cord of this tool,
it must be disposed of safely and not left unattended
USE
• On/off 7
• Switch locking for continuous use 8
! be aware of the forces that occur as a result of
jamming; hold the tool firmly with both hands and
take a secure stance
• Maximum speed control 9
With wheel C the maximum speed can be adjusted from
low to high (1-8+MAX)
- switch on the tool
- lock the switch
- turn wheel C to select maximum speed
• Mechanical gear selection 0
- set selector D to desired speed
! actuate the gear selector only when tool is
switched off
1 = LOW SPEED
- high torque
- for mixing high-density substances
2 = HIGH SPEED
- lower torque
- for mixing liquid substances
• Operating the tool
! ensure that the tool is switched off
- mount mixing paddle F onto spindle E as illustrated !
- connect plug to power source
- ensure the mixing container is securely positioned on
the floor
- dip the mixing paddle into the substance to be mixed
- set wheel C 2 in position "1"
- switch on the tool
- gradually increase the mixing speed by turning wheel
C 2 to the desired maximum speed (so that the
substance will not splash around)
! switch the tool off only when the mixing paddle is
in the mixing container
• Electronic soft-start
Ensures reaching the maximum speed smoothly without
a sudden impact when tool is switched on
• Electronic constant speed
Keeps the speed at a constant level as the load increases
• Electronic overload protection
- reduces the mixing speed automatically in case the
tool is overloaded for a longer period of time
- release switch A 2 briefly for returning to normal
working speed
• Holding and guiding the tool @
! while working, always hold the tool at the
grey-coloured grip area(s)
! always hold the tool firmly with both hands
MAINTENANCE / SERVICE
• Always keep tool and cord clean (especially the
ventilation slots)
- always clean the mixer and functional parts after your
mixing work
- clean the tool with a dry, soft cloth (do not use cleaning
agents or solvents)
- clean ventilation slots G 2 regularly with a brush or
compressed air
! disconnect the plug before cleaning
• AUTO-STOP Carbon brushes
- this tool is equipped with carbon brushes which pop
up automatically when worn, thus preventing the motor
from being damaged
- when the tool stops unexpectedly, send it to your
dealer or the nearest SKIL service-station for having
the brushes replaced
• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skil.com)
