Multi-surface leveling laser 502
INTRODUCTION
●
This tool is intended for aligning objects and/or marking
desired cutting lines by means of a straight laser line
projection; with the accessories supplied the tool can be
used on a variety of surfaces
●
Carefully read this instruction manual as well as the
warning label on the tool, before you use the tool 1
●
Pay special attention to the safety instructions and
warnings; failure to follow these may result in
serious (eye) injury
●
Before using the tool for the first time, paste the supplied
sticker in your national language over the English text of
warning label F 3
●
Save this instruction manual for future reference
TECHNICAL SPECIFICATIONS
Laser type 635 nm
Laser class 2
Maximum power output 1 mW
Power supply 3 x AG13 button cell battery
Operating temperature -10°C to 40°C
Storage temperature -20°C to 60°C
Weight 0,05 kg
Accuracy deviation of +/- 10 mm at
5 metres' distance
SAFETY
●
Do not look into the laser beam (laser radiation) 2
●
Do not point the laser beam at persons or animals
●
Do not place the tool in a position that may cause
anyone to look into the laser beam intentionally or
unintentionally
●
Do not use any magnifying optical tools (such as
magnifying glasses, telescopes, or binoculars) to view
the laser beam
●
Do not remove or damage the warning label on the tool
●
Do not operate the tool in the presence of flammable
liquids, gases or dust
●
Do not operate the tool with children around
●
This tool should not be used by people under the age of
16 years
●
Do not use the tool for any purpose other than those
mentioned in this instruction manual
●
Only use the original accessories which are intended for
this tool
●
Always switch off the tool when not in use
TOOL ELEMENTS 3
A On/off switch
B Bubble level for horizontal lines
C Bubble level for vertical lines
D Laser light opening
E Battery compartment cover
F Warning label
G Suction accessory
H Clamp accessory
J Pin accessory
K Magnet accessory
L Screw accessory
M Pivot accessory
N Belt clip accessory
USE
●
On/off
- before first use, remove protective insert as
illustrated 4
- switch on/off the tool by pushing switch A
! do not look into the laser beam
! do not point the laser beam at persons or animals
! always switch off the tool after use
●
Changing batteries 5
! ensure that the tool is switched off
- remove cover E
- insert 3 x AG13 button cell battery (pay attention to
correct polarisation)
- mount cover E
- always remove the batteries from the tool, if the tool
is not used for a long period
- always replace the complete set of batteries
●
Operating the tool 6
- when projecting a horizontal line, ensure that the
bubble in level B is centered
- when projecting a vertical line, ensure that the bubble
in level C is centered
- make measurements using the projected line as
reference
- when projecting a laser line at a longer distance, you
may increase its visibility by placing an object at the
end of the desired distance 7
●
Suction accessory G 8
For projecting lines on smooth surfaces
- slide tool on accessory G
- place accessory G onto surface
- level the tool (ensure that the bubble in the relevant
level is centered)
- push 2 knobs
- use projected line as reference
●
Clamp accessory H 9
For projecting lines on board materials (thickness 15 -
30 mm)
- slide tool on accessory H
- fasten accessory H onto board by turning knob
clockwise
- use projected line as reference
●
Pin accessory J 0
For projecting lines on plasterboard, soft wood, and
other soft materials
- slide tool on accessory J
- place accessory J onto surface
- level the tool (ensure that the bubble in the relevant
level is centered)
- push 2 knobs
- use projected line as reference
! be aware of the sharp pins
●
Magnet accessory K !
For projecting lines on any ferrous metal surface or profile
- slide tool on accessory K
- place accessory K onto surface
GB
7
