7
ENGLISH
Explanation of general view
1 Cutting action changing lever
2 Switch trigger
3 Lock button
4 Speed adjusting dial
5 Blade holder
6 Bolt
7 Hex wrench
8 Blade
9 Roller
10 Hook
11 Retainer
12 Base
13 Dust cover
14 Cutting line
15 Edge
16 Graduation
17 Starting hole
18 Hose
19 Steel base type
20 Rip fence (Guide rule)
21 Aluminum base type
22 Guide facing
23 Fence guide
24 Threaded knob
25 Pin
26 Anti-splintering device
27 Protrusions
28 Aluminum base
29 Cover plate
SPECIFICATION
• Due to our continuing programme of research and
development, the specifications herein are subject to
change without notice.
• Note: Specifications may differ from country to country.
Intended use
The tool is intended for the sawing of wood, plastic and
metal materials. As a result of the extensive accessory
and saw blade program, the tool can be used for many
purposes and is very well suited for curved or circular
cuts.
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply.
They are double-insulated in accordance with European
Standard and can, therefore, also be used from sockets
without earth wire.
General Power Tool Safety Warnings
WARNING! Read all safety warnings and all instruc-
tions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and
instructions for future reference.
Work area safety
1.
Keep work area clean and well lit. Cluttered and
dark areas invite accidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while oper-
ating a power tool. Distractions can cause you to
lose control.
Electrical safety
4.
Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
5. Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
6. Do not expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the
risk of electric shock.
7. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
Model 4326 4327 4328 4329
Length of stroke 18 mm 18 mm 18 mm 18 mm
Blade type B type
Max. cutting
capacities
Wood 65 mm 65 mm 65 mm 65 mm
Mild steel 6 mm 6 mm 6 mm 6 mm
Strokes per minute (min –1 ) 3,100 500 – 3,100 500 – 3,100 500 – 3,100
Overall length
217 mm
(Steel base type)
217 mm
(Steel base type)
217 mm 223 mm
223 mm
(Aluminum base type)
223 mm
(Aluminum base type)
Net weight
1,8 kg
(Steel base type)
1,8 kg
(Steel base type)
1,8 kg 1,9 kg
1,9 kg
(Aluminum base type)
1,9 kg
(Aluminum base type)
Safety class /II
