en Original Instructions for Drill.
Symbols, abbreviations and terms used.
Symbol, character Explanation
Do not touch the rotating parts of the power tool.
Make sure to read the enclosed documents such as the Instruction Manual and the General
Safety Instructions.
Observe the instructions in the text or graphic opposite!
Before commencing this work step, pull the mains plug out of the socket. Otherwise there will
be danger of injury if the power tool should start unintentionally.
Use eye protection during operation.
Use ear protection during operation.
Gripping surface
Confirms the conformity of the power tool with the directives of the European Community.
This sign indicates a possible dangerous situation that could cause severe or fatal injury.
Worn out power tools and other electrotechnical and electrical products should be sorted
separately for environmental-friendly recycling.
Product with double or reinforced insulation
1st gear/2nd gear
Low speed
High speed
WARNING
Character Unit of measurement,
international Unit of measurement,
national Explanation
P
1
W W Power input
P
2
W W Output
U V V Rated voltage
f Hz Hz Frequency
n
0
/min, min -1 , rpm,
r/min
rpm No-load speed
n
1
/min, min -1 , rpm,
r/min
rpm Speed, full load
M... mm mm Size of metric thread
Ø mm mm Diameter of a round part
mm mm Drilling diameter, steel
mm mm Drilling diameter, aluminium
mm mm Drilling diameter, wood
mm mm Tap
mm mm d1 = Clamping range of drill chuck
d2 = Shank size of drilling shaft
d3 = Collar diameter
kg kg Weight according to EPTA-Procedure 01/2003
L
pA
dB dB Sound pressure level
Fe
Al
