4
For cable selection, refer to the following table：
Network Speed Cable Type Max. Length
10Mbps Cat. 3, 4, 5 UTP/STP 100 meters
100Mbps Cat. 5 UTP/STP 100 meters
Rack-Mount
The switch may standalone, or may be mounted in a standard
19-inch equipment rack. Rack mounting produces an orderly
installation when you have a number of related network devices.
The switch is supplied with two optional rack mounting brackets
and screws. These are used for rack mounting the unit.
Specification
Standard
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x full duplex operation and
flow control
Interface
16/ 24 * 10/100Mbps RJ-45 Fast
Ethernet Ports
Uplink Auto MDI/MDI-X(Auto crossover)
Network Speed
10/100Mbps & Full/Half duplex mode
auto detection
MAC Addr. Table 8K MAC entries
Memory 160Kbytes
Power Supply
Internal Power supply
3.3V 4A (100-240V/ 50-60Hz)
EMI CE and FCC class A
