21

Chapter 4: Using the Utility Software

4.1 Main Tab

The “Main” tab provides a list of powerline adapters connected to the network. The

upper panel displays local powerline adapters. The lower panel displays remote powerline
adapters in the network.

Set Name

Select a device and click “Set Name” to rename the device.

Enter Password

By default, this column is blank. Select a device and click
“Enter Password” to set up a password for the device.

Scan

Click “Scan” and the utility software will perform an
immediate scan of other remote powerline adapters. By
default, the utility automatically scans every few seconds.
