2.3 LEDs
Ethernet
Port
Green
On
Ethernet connection established
Flashing Network activity
Off
No Ethernet connection
Power
Green
On
Powered on
Flashing
In power saving mode
Device resetting
Synchronizing password
Off
Powered off
PLC
Green/
Orange/
Red
On
Green: PHY RATE > 80Mbps
Orange: 40Mbps < PHY RATE < 80Mbps
Red: PHY RATE < 40Mbps
Off
Not in a powerline network
