Edimax Technology AR-7267WnB User Manual
Page 5
4
5) Local Area Network (LAN)
The router’s 4 LAN ports are where you connect your LAN’s PCs, printer servers, hubs and switches
etc.
6) ADSL
Connect the supplied RJ‐11 telephone cable to this port and connect it to your ADSL/telephone
socket.
Front LEDs
On the router’s front panel, there are LED lights showing the router’s current status. Below are the
description and explanation of each LED.
LED
Light
Status
Description
PWR
On
The router is ready
WLAN
(Yellow)
Off
Wireless LAN is disabled
Blinking Wireless network traffic is transmitting
ADSL
(Green)
On
Connected to an ADSL broadband connection successfully
Blinking No ADSL broadband connection
LAN
(Port 1‐4)
On
The LAN cable is connected to the router
Blinking Network traffic is transmitting through the LAN port
