LED Status:
LED Name Light
Status
Description
PWR
On
Switch is on
Off
Switch is off
LNK/ACT
On
Corresponding port is connected
Off
Corresponding port is not connected
Flashing Corresponding port is active and transferring
/receiving data.
Back Panel
ES-3305P
ES-3308P
ES-3308P
Operating Environment
This switching hub must be installed and operated within the limits of the
specified operating temperature 0~40°C (32~104°F) and humidity (10~90%
Non-condensing).
- Do not place objects on top of the unit.
- Do not obstruct any vents at the sides of the unit.
5V DC Power Port
5V DC Power Port
RJ-45 Ports 1 - 5
RJ-45 Ports 1 - 8
5V DC Power Port
RJ-45 Ports 1 - 16
