MUSWN2 WIRELESS OPTICAL MOUSE

Features

Wireless optical mouse with USB receiver

The tiniest receiver in the world can be stored inside the mouse

Smart power saving provides extra long batteries life

Special button for switching the resolution 800/1600 DPI



Specifications

Wireless technology: 2.4 GHz, GFSK RF modulation, 80 channels,
32 bit device ID, RF power < 2 mW

Operating distance: up to 8 m

Optical resolution: 800 or 1600 DPI selectable by the button

Power supply: AAA battery x 2 pcs

Power consumption: 5 V DC, up to 30 mA, saving modes < 3 mA
and < 0.5 mA, up to 35 hours continuous work with 1000 mAH
batteries

Nano receiver: USB 1.1 compatible, weight 2 g, 6 x 14 x 21 mm

Mouse: dimensions 99 x 62x 35 mm, net weight 60 g (without
batteries)

Operating conditions: -5...45 Celsius degrees, 10-80 % humidity
