14
TI 15 GB
4 Machine features
Accessories shown or described are sometimes not
included in the scope of delivery.
The specified illustrations appear at the beginning
of the Operating Instructions.
5 Intended use
Cordless impact screw driver is suitable
– for tightening screw fittings and screwing in
screws up to the maximum dimension range
stated
– drilling into metal, wood, plastics and similar
materials
– use with Festool batteries BPC and BPS of the
same voltage.
The device must not be used for applications which
require a precise/specific torque. When using the
device for applications which require a specific
torque or for which a maximum torque must not be
exceeded, there is the risk of overspeeding or dam-
age to the screw or the workpiece.
Charger TCL 3 suitable for
– charging Festool battery packs: BP, BPS and
BPC (NiMH, NiCd, li-ion are recognised automat-
ically.)
– indoor use only.
The user is liable for improper or non-in-
tended use; this also includes continuous in-
dustrial operation.
6 Operation
6.1 Charger cable holder[3-3]
Unwind the cable completely from the recess
before using the charger.
Charger TCL 3
Mains voltage (input) 220 - 240 V ~
Mains frequency 50/60 Hz
Charging voltage (output) 10,8 - 18 V=
Rapid charging max. 3 A
Conservation charging, intermittent (NiCd, NiMH) approx. 0,06 A
Charging times for BP, BPS and BPC battery packs
Li-ion 1,5 Ah, 80 %/100 % approx. 25/35 min.
Li-ion 3,0 Ah, 80 %/100 % approx. 55/70 min.
Li-ion 4,2 Ah, 80 %/100 % approx. 70/90 min.
Permitted operating temperature range -5 °C to + 45 °C
Temperature monitoring via NTC resistor
Safety class /II
Battery pack BPC 15 Li
Voltage 14,4 V
Capacity 4,2 Ah
Weight 0,58 kg
[1-1] Bit store
[1-2] On/Off switch
[1-3] Right/left switch
[1-4] LED lamp
[1-5] CENTROTEC tool chuck
[1-6] Thumbwheel Speed/Impact rate
[1-7] Capacity display
[1-8] Battery pack
[1-9] Belt clip
[1-10] Buttons for releasing the battery pack
[1-11] Adapter for FastFix attachments
[1-12] 13 mm chuck
[1-13] Elbow adapter
[3-1] Charger
[3-2] LED-Display
[3-3] Cable holder
[3B] Wall mount
