14

cut-in of the appliance also operates in

conjunction with compressed-air tools. We

also recommend fi tting of the VE supply

unit (452797). The supply unit fi lters and

oils the compressed air and allows the air

pressure to be regulated. An IAS connecting

piece (454757) is available for connecting

Festool compressed-air tools with the IAS

system. To ensure trouble-free functioning

of the automatic cut-in, the operating pres-

sure of the tool must be 6 bar.

4 Operation

4.1

Opening/closing the vacuum

cleaner

- Open retaining clamps (2.2),

- Raise upper part (2.4) until support catch

(2.5) engages.

Follow the reverse order to close the ap-

pliance. You must raise the upper part

slightly before depressing or disengaging

the support.
4.2 Changing

the

fi lter

During the following procedure, take

care not to raise dust more than is

unavoidable.

Wear a P2 breathing protection mask

with health-hazardous dusts!

a) Changin

the

fi lter bag (3.4)

Order no.:

CTL 22 E SG

452970

CTL 33 E SG/CTL 33 LE SG

452971

CTL 44 E/CTL 44 LE

452972

CTL 55 E

452973

- Open the vacuum cleaner,

- Remove the used fi lter bag (see printed

text on fi lter bag),

- Dispose of the used fi lter bag in accord-

ance with statutory requirements,

- Thoroughly clean the dirt container (2.10)

and the space (3.1) for suction turbine

(wipe down with a damp cloth),

- Insert new fi lter bag (see printed text on

fi lter bag). Important: Press the fi lter

bag sleeve (3.3) fi rmly onto the dust ex-

traction fi tting (3.2)!

- Close the vacuum cleaner.
b)

Changing the filter element

(2.3)

Order no.:

452923

Do not operate machine without a

fi lter element. This may damage the

motor.

- Open the vacuum cleaner,

- Remove the used fi lter element (see print-

ed text on the fi lter element packaging),

- Dispose of the used fi lter element in a

sealed, dust-tight bag in accordance with

statutory requirements,

- Thoroughly clean dirt container (2.10) and

space (3.1) for the suction turbine (wipe

down with a damp cloth),

- Fit a new fi lter element (see printed text

on the fi lter element packaging),

- Close vacuum cleaner.
4.3 Cleaning

the

fi lter element

To clean, move the handle (2.1) to and fro

about 10 times. N.B.: You need to clean the

fi lter element only if you use the vacuum

cleaner without a fi lter bag.
4.4

Emptying the dirt trap (2.10)

Always remove the upper part of the

vacuum cleaner before emptying the dirt

container!

- Open the vacuum cleaner,

- Raise the upper part slightly, depress the

support (2.5),

- Raise the upper part to the stop (vertical

position),

- Remove the upper part by moving it for-

wards horizontally,

- Empty the dirt container,

- Replace the upper part. Warning: Make

sure that both upper-part pins are fully

inserted in the recesses (1.5)!

- Close the vacuum cleaner.
4.5 Stand/Brake

The wheels can be blocked by the brakes

(2.8), thus preventing the vacuum cleaner

from rolling away unexpectedly.
4.6

Hose depot (partly in scope of

delivery)

Securing the hose depot on the dust extrac-

tor: see Fig. 4. When work is complete, you

can guide the extractor hose through the

opening (4.1) and deposit the hose in the

depot. Similarly, the mains cable can also

be guided through the opening (4.2) and

deposited in the hose depot.

5 Application

- A systainer can be fi xed to the storage

area (1.9) with the two clamps (1.11).

Tools or accessories can also be stowed

on the storage area and in the storage

compartments (1.6, not with CTL 22).
